1000 x 1200 mm Frameless Triple Glazed Flat Roof Skylight

Enhance your space with the 1000 x 1200 mm Triple Glazed Flat Roof Skylight. Designed for optimal insulation and noise reduction, it features advanced self-cleaning glass, UV protection, and an ultra-low U Value of 0.9 W/m²K.

🔍 Key Specifications

• Glazing Type: Triple Glazed

• Internal Glass Size (Quoted): 1000 x 1200 mm

• External Glass Size: 1200 x 1400 mm

• U Value: 0.9 W/m²K

• G Value: 58%

• Sound Reduction: 39 dB (EN 12758)

• Glass Tint: Clear

• Net Weight: 61.20 kg

• Self-Cleaning: YES

• UV Protected: YES

🧪 Glazing Structure

• Top Pane: 6 mm Planibel Clearlite (Thermally Toughened, BS EN 12150)

• Spacer: 15 mm Black Warm Edge

• Air Gap: 15 mm, 90% Argon Filled

• Middle Pane: 6 mm iplus Thermally Toughened Glass with Low-E Coating (EN 12150)

• Spacer: 15 mm Black Warm Edge

• Air Gap: 15 mm, 90% Argon Filled

• Bottom Pane: Stratobel Clearlite 44.2 (Laminated, EN 14449)

🛡️ Safety & Certifications

• ✅ CE Marked for EU compliance

• ✅ Meets British Standards & Building Regulations

• ✅ Fully Toughened & Laminated for Impact Resistance

• ✅ Max Roof Pitch Installation: 45°

🧰 Installation Guidelines

• Black Border: Adds 200 mm to internal size externally

• Opening Size: Add +10 mm to internal – for 1000 x 1200, opening = 1010 x 1210 mm

• Upstand: Use 2×1″ or 2×2″ timber construction

• Sealant: Dowsil 791 (Black) – do not use acrylic sealants

• Foam Rope: Apply above internal baton to distribute weight evenly

📦 Included Features

• 20-Year Manufacturer Warranty

• Made in EU

• All Glass – Toughened and Laminated

• Free Delivery within London (M25)

• Frameless, Modern Appearance

• Clear Tint – Brighter Interiors

• Compatible with Custom Size Calculators

• Quick and Simple Installation

• Step-by-Step Installation Guide

• 24/7 Technical Support Available

💡 Why Choose Saris-Extensions Skylights?

More than just a skylight, it’s a step toward a brighter, more energy-efficient lifestyle. Our precision-engineered units offer maximum daylight, modern design, and long-term performance—perfect for both residential and commercial projects.
